World-famous Pfeiffer vacuum station made in Germany consists of diaphragm pump as backing pump and turbo-molecular pump, with complete accessories, including vacuum gauge with KF25 port , SS vacuum bellows with KF40 port, & LCD digital display and ball valve together, right now bring the customer a plug-and-play system with vacuum range from 1E-3 to 1E-7 mbar, which means the customer just presses the power switch and then get high vacuum level in short time at very low noise. It is an ideal tool for most of MTI's tube furnace to achieve high vacuum >10-4 torr

Specifications
Connection	● Molecular pump with KF40 to T type of Vacuum Tube and KF25 to Vacuum Gauge ● Vacuum gauge with KF25 port to install to T -tube ● Right angle high vacuum valve with KF40 port , which connects between T- vacuum tube and SS vacuum bellows ● 600 mm length SS vacuum bellows with KF40 port to connect to furnace flange ● One KF40 to KF25 adapter is included to connect the pump to MTI's furnace which has KF25 port on flange ● Please click the picture left to see detailed information:
Volume Flow Rate	● Nitrogen N2 33 L/s ● Helium He 39 L/s ( 2340L/minute) ● Hydrogen H2 32 L/s
Compression Rate	● Nitrogen N2 >1E11 ● Helium He 6*1E6 ● Hydrogen H2 >1E5
Ultimate Pressure	<1E-8 mbar (without any leaking )
Start-up Time	2 Min.
Working Range	From 1000 mbar to <1E-7 mbar
Backing Pump's Pumping Speed	0.9m^3/H at 50Hz and 1.0m^3/H at 60Hz
Duration /max. power	100/110 W
Mains Connection	90-132 V/ 185-265V (Universal)
Weight	15 Kg
Warranty	One year manufacture warranty. (Attention: The use of corrosive and acidic gas is prohibit! In order to avoid any damages to pump, please consult with MTI engineers for adding an appropriate inlet gas filter for your specific application.)

Standard Package
P/N	Description	Quantity	Picture&Link
EQ-KF-Valve-D40	KF-40 Vacuum Right-Angle Valve	1
EQ-KF-Pipe-D40	KF-40 SS Vacuum Bellows (600 mm )	1
EQ-KF-Clamp-D40	KF-40 Quick Clamp with Rubber O-Ring	3
EQ-KF-Clamp-D25	KF-25 Quick Clamp with Rubber O-Ring	1
EQ-KF-RT-40-25	Reducing T-Tube : two KF40port and one KF25 port	1
EQ-RU-KF40-25	KF40 to KF25 adapter	1
EQ-PV-Sensor	Vacuum gauge with KF25 & cable	1

MTI keeps high quantity in inventory for fastest delivery in US, see below picture MTI is doing batch test in the lab:
